Name: Tronxy Moore 2 Pro Clay 3D Printer with Feeding System Print Size 255x255x260mm
SKU: 313691

Product Details ＋

Versatile Printing Capabilities

The Tronxy Moore 2 Pro is designed for printing with ceramic and clay materials, allowing you to create intricate and customized designs. The spacious print area of 255mm x 255mm x 260mm offers the flexibility to work on various projects, from artistic sculptures to functional items.

User-Friendly Feeding System

Equipped with an advanced feeding system, the Tronxy Moore 2 Pro ensures a smooth and consistent flow of materials. The electric putter enhances the efficiency of the printing process, minimizing jams and maximizing productivity.

Sturdy Construction

Built with high-quality materials, the printer exhibits exceptional durability and stability. This robust design not only enhances print quality but also prolongs the printer's lifespan, making it an excellent investment for both hobbyists and professionals.

Enhanced Precision and Accuracy

Experience remarkable precision with the Tronxy Moore 2 Pro. By utilizing cutting-edge technology, this printer achieves precise layer adhesion and accurate detailing, resulting in stunning end products that exceed expectations.

Easy Setup and Operation

The Tronxy Moore 2 Pro is designed for hassle-free setup and operation. With a user-friendly interface and straightforward instructions, even beginners can quickly learn to produce high-quality prints like seasoned professionals.

Innovative Design Features

Incorporating innovative design features, the Tronxy Moore 2 Pro enhances the user experience. From its sleek appearance to thoughtfully arranged components, every detail is aimed at ensuring easy access, maintenance, and usability.

Steps/mm: 0.7
Extruder design files are not open source
The 3d printer already includes each item, if you need the extra tube, nozzle needle, printing head, microwave kiln, clay, etc, you can purchase them with the 3d printer.

Tronxy Moore 2 Pro Ceramic 3D Printer Clay 3D Printer 255mm 3D Printer Feeding System Electric Putter 3D Printing Technology Tronxy 3D Printer

Tags: , , , , , , ,

TRONXY MOORE 2 PRO CERAMIC & CLAY 3D PRINTER

Touch screen

Resume after power failure

Clay, ceramic slurry, and various liquid flowing materials

Feeding system electric putter

32 Bit Silent Mainboard

Exclusive OSG Dual Core Guide Rail

High Efficiency And Quality

Inheritance & Technology & Innovation

The design requires careful attention to every detail, just to make the best clay 3D printer. Just to provide customers with a better experience.

Pottery Heritage Technological innovation

Inheritance & Technology & Innovation

Printing Principle:	Liquid Flow Stacked Molding (LDM)
Printing Thick Layers:	0.3-3.0mm
Positioning Accuracy:	X/Y: 0.00625mm; Z: 0.00125mm
Printing Speed:	10-40mm/s (20mm/s is recommended)
Display Screen:	Full Color Touch Screen
Nozzle Diameter:	1.0-3.0mm (optional)
Number of Nozles:	Single Nozzles
Print Volume:	255255260mm
Materials:	Pottery Clay, Porcelain Clay, Purple Sand, Other Liquid Flowing Material
Colour:	White
Language:	Eight Languages
Material:	Sheet Metal
Input Format:	.stl / .obj / .dae / .amf
Slicing Software:	Cura / Repetier-Host
Output Format:	Gcode
Printing Method:	USB Cable, TF Card
Machine Weight:	18.5KG 3.5KG = 22KG
Package Size:	740532215mm
Machine Size:	410414510mm
Barrel Capacity:	500ml

Frequently Asked Question

Q: Is there a small size for the clay barrel? 500ml is too big for us. The sample quantity of our printing is very small. If not, is it possible to customize. What is the price of customization?
A: The barrel capacity 500ml is the smallest. Temporarily do not accept customize.
Q: Nozzle is different because of the caliber, does it match the software settings? Or the software settings are the same and have nothing to do with the caliber.
A: If you change a different nozzle, you need to set the size of the corresponding nozzle on the slicing software.
Q: Is the extrusion speed controlled by software?
A: The printing speed can be set on the software, the default printing speed is 30 is the best.

Clay 3D Printer Body * 1

Screw Print Head * 1

Feed Teansmission * 1

M18 Extrusion Screw * 1

Allen Wrench * 1

Barrel Holder * 1

Barrel (500ml) * 2

Power Cable * 1

Plastic Wrap * 1

Material Pipe (φ10*8mm) * 1

TF Card and Card Reader * 1

Spare Nozzle (φ10*8mm) * 2

Pottery Clay Printing Needle (12pcs) * 1

Ceramic Mud (2KG) * 1

Fiberglass Board (2pcs) * 1

Specification

Print size: 255*255*260mm
Print speed: 10-40mm/s (20mm/s is preferred)
Print thickness: 0.3-3mm (Optional)
Positioning accuracy: X/Y:0.00625mm; Z:0.00125mm
Nozzle size: 1-3 mm (Optional)
Materials support: Clay, Ceramics slurry, Red Porcelain and various liquid flowing materials
Machine weight: 15 kg 3.5kg
Machine size: 410mm * 414mm * 510mm
Package Size: 740mm * 532mm * 215mm
Barrel Capacity: 500ml

What is the most suitable viscosity for mix mud for Tronxy Moore Clay 3d printer?

Usually our customer mix the mud alreays too dry or too wet. What kind of viscosity for the mud is the most suitable for printing on our clay 3d printer. Pls follow above the first video guide, for Moore 1, Moore 2, Moore 2 pro.

Software And Other Paramenters

Slicing software: Cura
Output format: G-Code
Operation software: Repetier-Host/Cura
Operation system: Windows
Connection: USB cable, TF card
Power input: 100V/220V, 50/60Hz
Power output: 24V/360W
Input format: .stl, .obj
Language: Eight Language

Packing list

Gantry

Base

Screw printer head

Feeding System (Trasmmision M18 extusion screw)

Barrel holder & Barrels * 2pcs

Fiber Glass Plate

Reader with 8G TF card

Ceramic Mud 2kg

Pipes (Φ10 * 8mm)

Pottery clay printer needle (1 box) Spare pneumatic connector)

Tools（ Power cable, manual, plastic wrap, etc)

MORE STABLE OSG Guide Rail

Exclusive OSG Dual Core Guide Rail

OSG Guides More Stable And high Precision Extended Service life.

Mute Motherboard No Noise in Printing

Easy to operate with touch screen One-key quick printing.

User Manual Documentation

Clay 3D Printer Applications

Art work

Pottery bar

Sculpture art

Cultural relic restoration

IP animation

Ceramic art customization

Once You Have It

The integration of creativity and technology greatly shortens the creative cycle.

Sketch printing products

The artistic combination of clay and line.

Glaze Firing Effect

One color in the kiln, Out of the Kiln Mutiple Colors.

Achieves the Future Creative possibilities

Watch More

Tronxy Moore 2 Pro Ceramic & Clay 3D Printer Installation Video

What is the Most Suitable Viscosity for Mix Mud for Moore Printers

How to Clean the Clay Print Head for Moore Series 3D Printers

Moore Clay 3D Printers

(scroll to view all):

Moore Series 3D Printers	Moore 1	Moore 2	Moore 2 Pro	Moore 3	Moore 3 Pro
Build Size	180x180x180mm	255x255x260mm	255x255x260mm	330x330x370mm	330x330x370mm
OSG Guides *	✓	✓	✓	✓	✓

* OSG Guides: Exclusive OSG dual core guide rail more stable and high precision extended service life.

Complete Constant Temperature Clay 3D Printers

Contact us to PRE-ORDER the custom clay 3d printers.

Timeline: Custom the 3d printer takes 40-45 days.

(scroll to view all)

Photo	Model	Print Size (mm)
	Black and White Color 2 Options
	Moore X2525	255x255x260
	Moore X2540	255x255x400
	Moore X3350	330x330x500
	Moore X4060	400x400x600
	Moore X4080	400x400x800
	Moore X5070	500x500x700
	Moore X50100	500x500x1000
	Moore X6080	600x600x800
	Moore X60100	600x600x1000
	Moore X60120	600x600x1200
	Moore X80120	800x800x1200
	Moore X80160	800x800x1600
	Moore X100160	1000x1000x1600
	Moore X100200	1000x1000x2000

More about Moore 2 Pro

Q: What is the Tronxy Moore 2 Pro Clay 3D Printer?
A: The Tronxy Moore 2 Pro Clay 3D Printer is a special type of printer that uses clay instead of regular plastic to create 3D objects. It has a feeding system that helps move the clay smoothly, making it easier to print beautiful and detailed designs.
Q: How does the feeding system work?
A: The feeding system in the Tronxy Moore 2 Pro is like a strong push that helps the clay get into the printer. This system ensures that the right amount of
